Long Cycle Life LFP150Ah (LiFePO4 150Ah Battery) Cell
- Lifepo4 Cells 150ah is 3.2V 150ah prismatic lithium iron phosphate batteries,
- Weight: 2.80±0.0.08kg,
- Energy density: 172Wh/kg,
- Cycle life: ≥4000 times
Product Description
Long Cycle Life Lifepo4 150Ah Battery Description
| LITHIUM STORAGE can offer different terminal solutions for cells with welding terminals, including screw terminals and Nut terminals. These solutions have passed multiple inspection testing items such as drawing force, shear force, and torque testing, etc., and have been applied in various electric vehicle and energy storage projects in different countries. |  |
| No. | Item | Specification | Note |
| 1 | Rated Capacity | 150Ah | @1C,25±2℃ |
| 2 | Nominal Voltage | 3.22V | |
| 3 | Actual Voltage Range | 2.5-3.65V | |
| 4 | Constant Discharge Current | ≤150A | Typical value=67.5A |
| 5 | Peak Discharge Current | ≤450A | @60s |
| 6 | Constant Charge Current | ≤150A | Typical value=67.5A |
| 7 | Peak Charge Current | ≤300A | @30s |
| 8 | Operating Temperature | Charge:0℃~55℃ Discharge:-30℃-55℃ |
|
| 9 | Storage Temperature | 30C-60°C | |
| 10 | Cell Dimensions |
Thickness:36.30±0.50mm Length:174.00±0.50mm Height:204.40±0.60mm |
|
| 11 | Cathode Material | LFP | |
| 12 | Weight | 2.80±0.08kg | |
| 13 | Energy density | 172Wh/kg 365Wh/L | |
| 14 | Cycle life | ≤4000times | @0.5C,100%DOD |
| 15 | Terminal | Welding/Screw/Nut terminal |
 |
To suit the various connection demand from customers, it is available to support cells with screw terminals or nut terminals excepting welding terminals. The relevant torque is recommended for avoiding excessive force which can damage the terminal thread when the bolts are tight.For applied bolts, busbar, and tighten torque are shown in the table below. |
| Parameter table | |||||||
| Cell type | Screw Terminals | Nut Terminals | Fasten torque | Remark | Standard Busbar Type | Non-standardbusbar type | Current Capacity |
| LFP40Ah | / | M6*14 | 6N*m | Max repeated terminal screw times≤3 | BS1-LFP40A | BS2-LFP40A | 1C |
| LFP50Ah | / | M6*14 | 6N*m | BS1-LFP50A | BS2-LFP50A | 1C | |
| LFP100Ah | / | M6*14 | 6N*m | BS1-LFP100A | BS2-LFP100A | 1C | |
| LFP135Ah | / | M6*14 | 6N*m | BS1-LFP135A | BS2-LFP135A | 1C | |
| LFP205Ah | M6*16 Bolt | M6*18 | 6N*m | BS1-LFP205A | BS2-LFP205A | 1C | |
| LFP280Ah | M6*16 Bolt | M6*18 | 6N*m | BS1-LFP280A | BS2-LFP280A | 1C | |
| LFP280Ah long cycle | M6*16 Bolt | M6*18 | 6N*m | BS1-LFP280A | BS2-LFP280A | 1C | |
| LFP302Ah | M6*16 Bolt | M6*18 | 6N*m | BS1-LFP302A | BS2-LFP302A | 1C | |
| NCM102Ah | / | M6*18 | 6N*m | BS1-NCM102A | BS2-NCM102A | 1C | |
| NCM177Ah | / | M6*18 | 6N*m | BS1-NCM177A | BS2-NCM177A | 1C | |
| Cell type | LFP40Ah | LFP50Ah | LFP100/Ah | LFP135Ah | LFP205Ah | LFP280Ah | LFP280Ah long cycle | LFP302Ah | NCM102Ah | NCM177Ah | |
| Management System | ISO-9001 | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ |
| IATF16949 | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | |
| ISO-14001 | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | |
| ISO-45001 | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | |
| Products Certification | GB/T-31485-2015 | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ |
| GB/T-31486-2015 | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | |
| GB/T-31484-2015 | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | |
| IEC62619 | / | √ | √ | / | / | / | √ | / | / | / | |
| UL1642 | / | √ | / | / | / | / | / | / | / | / | |
| UL9540 | / | / | / | / | / | / | √ | / | / | / | |
| UL1973 | / | / | / | / | / | / | √ | / | / | / | |
| MSDS | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | |
| UN38.3 | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | |
| BIS | / | √ | √ | √ | / | / | / | / | / | / | |
| JET | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ |
| 01 Carton for air transportation and plywood case for sea transportation | 02 Meeting the UN38.3 package standard for dangerous goods |
The Long Cycle Life LFP150Ah LiFePO4 150Ah Battery offers versatility across a wide range of applications. It is an ideal solution for residential energy storage systems, allowing homeowners to store and utilize excess energy generated by renewable sources or the grid. By reducing reliance on the grid, homeowners can take control of their energy usage, potentially leading to significant cost savings and a more sustainable lifestyle.
Commercial and industrial applications can also benefit from the Long Cycle Life LFP150Ah LiFePO4 150Ah Battery's capabilities. From peak shaving and load balancing to backup power supply and grid stabilization, this battery provides a reliable and efficient solution for various energy storage needs. Its versatility and performance make it a valuable asset in promoting a more sustainable and resilient energy infrastructure.
